ACB-2 HDG Beam Clamp for 1-5/8" (41x41) C Profile Strut

Heavy-Duty Beam Clamp — 1-5/8" (41x41) C Profile

The ACB-2 HDG is a hot-dip galvanized beam clamp engineered to secure 1-5/8" (41x41) strut channel to steel beam flanges without drilling or welding. Built for contractors and distributors who need dependable, load-rated cable management support in demanding industrial environments.

• Material & finish: Hot-dip galvanized (HDG) steel for superior corrosion resistance, indoor or outdoor
• Compatibility: Designed for 1-5/8" (41x41) C profile strut channel
• Base plate: 3-1/8" wide x 2-5/16" deep
• Overall height: 5-1/8" (3-1/4" U-bolt clamp depth)
• Bolt spacing: 2" center-to-center, twin-bolt clamping
• Flange grip: 135° angled jaw for a secure hold on beam flanges
• Installation: No drilling or welding required — clamps directly onto the beam

A reliable choice for overhead cable tray, conduit, and strut mounting where speed and strength matter.
